Place of Origin:
China
ब्रांड नाम:
Kacise
प्रमाणन:
CE
Model Number:
KC
Application
Back sonar of automobiles, Packing meters, Water level meters
Feature
1) Water proof and dual use
2) Compact and light weight.
3) High sensitivity and sound pressure
4) Less power consumption
5) High reliability
| Part Number | MSW-A36100H17TR-W |
| Construction | High-frequency |
| Using Method | Dual Use |
| Center Frequency | 300±8kHz |
| Bandwidth | 8.0KHz |
| Echo Sensitivity | -66dB min |
| Min. Parallel Resistance | 160Ω±30％ |
| Capacitance | 1100Pf±20％ |
| Max.Input Voltage | 600Vp-p |
| Directivity | 9°±2°(-6dB) |
| Distance of Detection | 0.2~4m |
| Protection Class | IP68 |
| Operating temperature | -20℃~+70℃ |
| Storage Temperature | --35℃~+85℃ |
| Housing Material | Aluminum |
