Name: KL Series Load Cell Sensor Multiple Models 5 - 15V
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: GXLC-DZ-0.5T
Price: 50 USD
Availability: InStock

घर > उत्पादों > लोड सेल सेंसर >

KL Series Load Cell Sensor Multiple Models 5 - 15V

15V Load Cell Sensor

300kg Load Cell Sensor

KL Load Cell Weight Sensor

Place of Origin:

China

ब्रांड नाम:

Kacise

Model Number:

GXLC-DZ-0.5T

हमसे संपर्क करें

बोली मांगें

KL Series Load Cell Sensor Multiple Models 5 - 15V

उत्पाद का विवरण

Capacity:

300kg

Rated output:

1.2±10%mV/V

Zero balance:

±1%F.S.

impedance:

700/1400ohm

Ultimate overload:

200%F.S

Safe overload:

150%F.S

Operation temp range:

-20~80 ℃

Recommended excitation:

5~15V

प्रमुखता देना:

15V Load Cell Sensor

300kg Load Cell Sensor

KL Load Cell Weight Sensor

भुगतान और शिपिंग की शर्तें

Minimum Order Quantity

मूल्य

50USD/pc

Packaging Details

carton

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100+

संबंधित उत्पाद

Weighbridge 5kg Electronic Strain Gauge Load Cell

सबसे अच्छी कीमत पाएं

Waterproof Round Load Cell Transmitter

सबसे अच्छी कीमत पाएं

0.5kg 1kg 2kg 3kg Stainless Steel Small Load Cell Sensor

सबसे अच्छी कीमत पाएं

Impact S - Beam Crane Scale Load Cell Sensor Strain Gauge High Precision

सबसे अच्छी कीमत पाएं

हमसे संपर्क करें

अब संपर्क करें

उत्पाद का वर्णन

GXLC-DZ-0.3T Load Cell

Specification

Item	Parameters
Capacity	300kg
Rated output	1.2±10%mV/V
Zero balance	±1%F.S.
Non-linearity	0.05%F.S
Hysteresis	0.05%F.S
Repeatability	0.03%F.S
Creep (30min)	0.03%F.S
Temp.effect on output	0.03%F.S/10 ℃
Temp.effect on zero	0.03%F.S/10 ℃
impedance	700/1400ohm
Insulation	≥5000M ohm/100VDC
Recommended excitation	5~15V
Operation temp range	-20~80 ℃
Safe overload	150%F.S
Ultimate overload	200%F.S
Cable size	Φ5x3000mm
